REDARC 3A Charge Equaliser
REDARC 3A Charge Equaliser
Couldn't load pickup availability
The REDARC 3A Charge Equaliser allows 12 volts to be ‘tapped’ from the centre of a series-connected, two battery, 24 volt DC electrical system while still ensuring an equal charge across the two batteries.
This is particularly useful when space or cost prohibits the installation of a separate 12 volt battery.
The advantage that a Charge Equaliser provides over a standard voltage reducers is that power is drawn from a battery rather than through a current limited device, allowing much larger peak and current draws.
The REDARC Charge Equaliser features overload protection and has a high peak current capability and fast transient response suited for loads requiring a safe, clean and stable 12 volt supply.
Benefits
- Designed to keep your 24 volt batteries equally charged
- Cost effective product for supplying 12 volts to any type of load
- Peak load currents available are limited only by the battery
Features
- High peak current capability
- Fast transient response
- Fully encapsulated
Specifications:
| Input (Operating) Voltage | 19 - 33VDC |
| Output Current Rating (Cont.) | 3A |
| Input Fuse Rating | 5A |
| Output Fuse Rating | 5A |
| Warranty | 2 Years |
| Output System Voltage | 12VDC |
| Length (mm) | 135 |
| Width (mm) | 75 |
| Height (mm) | 70 |
| Weight (kg) | 0.4 |
